Technical Guide • Plug-and-Play
Star Ceiling Installation.
Engineering professional starlit environments through our signature plug-and-play panel systems.
Professional Standards.
Installing a fiber optic star ceiling instantly elevates any space—from luxury home theaters to high-end casinos. WDM Lighting simplifies the complex through a modular panel system designed for precision results.
Every WDM Kit includes acoustical fiber optic panels, mounting anchors, the Epic Link controller, RJ45 quick-connect cabling, and a 12V power supply.
Recommended Tools.
Chalk Line
Grid AccuracyBox Cutter
Custom TrimmingPartner
Panel AlignmentAlso required: Painter's tape, 3M adhesive spray, and a steady ladder.
Power Specifications.
Your power supply wattage determines the maximum panel count for your DMX circuit.
10
25W Supply24
60W Supply40
100W Supply80
200W Supply120
300W Supply120+
Contact WDM01. Plan Your Layout
Mark the ceiling center with an "X". Use a chalk line to create a grid matching your panel dimensions (24"x24" or 24"x48") to ensure industrial-grade alignment.
02. Mount Anchors
Poke guide holes 4" in from each panel corner. Screw in Rotofast anchors and snap hex covers into place. Pro Tip: Use painter's tape to mark poke points before drilling.
03. Connect Power & Data
Plug the RS232 lead into the "IN" port of the first panel. Use jumpers to chain panels (OUT → IN). You should hear a clear click when the RJ45 is secured.
04. Drop Ceiling / Custom Cuts
For drop ceilings, place panels directly into the T-grid frame. For beams or vents, cut through the fiberglass (not fabric) on the back. Fold flaps, apply 3M adhesive, and press flat.
05. Special Effects
Set lighting modes via DIP switches or RS-232 commands. Available modes include Realistic Night Sky, Shooting Stars (10s to 10m intervals), Meteor Showers, and Scintillation.
Technical FAQ.
No. WDM's star panels are plug-and-play with RJ45 quick-connects. Basic tools and a partner for alignment are all you need for professional results.
Yes. Panels can be cut for custom layouts, and effects like realistic constellations or timed shooting stars are easily programmed via the Epic Link.
Absolutely. Fiber strands carry light only—zero electricity or heat reaches the ceiling surface. They are ideal for saunas, steam rooms, and pool enclosures.
Showcase: Shooting Star Casino
Our fiber optic star ceiling created a luxury atmosphere with twinkling skies and meteor effects—the same high-performance system available for your venue.
