24V Flat View LED Flex Neon RGB Spool

24V Flat View LED Flex Neon RGB Spool

$545.00$1,023.00

SKU: CL-C-FR-F15A-CV24 Category:

Product Description

Features:

  • Adopts tri-chip SMD5050 LED as its light source
  • Adopts first-class eco-friendly UV-resistant PVC material
  • Flat surface, continuous and uniform illumination, no LED dot or dark spot
  • Environmentally friendly and energy saving
  • Transverse minimum bending diameter: 12cm
  • Easy to be installed, can be cut and reconnected (connection accessories available)
  • Protection Rating IP68 (All joints and connectors must be hermetically sealed to achieve IP68)

Application:

Especially suitable for indoor and outdoor architectural outline decorations, walkway and park guiding-line lighting system, and landscaping.  Ideal for bridge, sculpture, building contour, and board fringe illuminating decoration

LED Neon Ribbon Light  (11.5*21mm)

  • LED Type SMD 5050 tri-chip
  • Material PVC-Ivory White
  • Working Voltage DC24V
  • Rated Power / mtr 12W
  • LED Qty/mtr 60LEDs
  • LED Distance 1.67cm
  • Min. Cutting Unit 6LEDs Min.
  • Cutting Length 10cm
  • Connection Length >10m 20 meter connection can be made if energized from both ends with 300W 24VDC Power Supply
  • IP Rating IP68/IP65
  • UL Listed

Download user manual.

Download specification sheet.

Download wiring diagram.
Download U.S. UL Certification
Download Canada UL Certification.
Download Cutting Increment Chart.

Additional Information

Weight 10 lbs
