WDM – Touch Panel LED Controller
Transform your lighting experience with the WDM – Touch Panel – the ultimate wall-mounted LED controller. Perfect for residential, commercial, and hospitality installations, this elegant 86mm touch panel provides sophisticated control for up to 600 pixels across SPI addressable and PWM LED strips with seamless 2.4G wireless connectivity.
Product Overview
Product Gallery
The WDM – Touch Panel represents cutting-edge LED control technology, combining elegant wall-mounted design with powerful 2.4G wireless control capabilities. This professional-grade controller supports both PWM and SPI addressable LED strips, offering unprecedented flexibility and sophisticated control for any lighting project. Model SP630E delivers reliable performance with CE and UL certification.
Key Features
🎛️ Professional Wall Control
Standard 86mm x 86mm panel design:
- Sleek, modern touch interface
- Fits standard wall boxes worldwide
- Premium build quality at just 12mm depth
- Operating temperature: -20℃ to 60℃
Professional appearance that complements any interior design.
📡 Advanced 2.4GHz Control
Powerful wireless connectivity:
- 30-Meter Range: Control from anywhere in large spaces
- 2.4GHz Frequency: Reliable, interference-free operation
- Multi-Device Support: Control multiple zones or systems
- CR2032 Battery: Long-lasting button cell power (included)
Seamless integration with WDM Lighting LED controllers.
💡 Universal LED Compatibility
One panel for all your LED installations:
- PWM LED Strips: 5050, 5630, 3528, COB (up to 12A total)
- SPI Addressable: Up to 600 pixels (RGB/CCT)
- SPI 4CH RGBW: Up to 450 pixels maximum
- SPI 5CH RGBCCT: Up to 300 pixels maximum
Compatible with all major LED strip types and chipsets.
⚡ Professional Power Handling
- Voltage Range: DC 5V-24V (flexible installation)
- Working Current: 3mA-13mA (efficient operation)
- PWM Single Channel: 6A maximum output
- PWM Total Output: 12A maximum combined
Professional-grade performance for demanding installations.
Supported LED Strip Types
SPI Addressable LED Strips
Full support for individually addressable LED strips with dynamic effects:
- Monochrome/CCT/RGB: Up to 600 pixels
- 4-Channel RGBW: Up to 450 pixels maximum
- 5-Channel RGBCCT: Up to 300 pixels maximum
- Compatible with WS2811, WS2812B, WS2813, WS2814, WS2815, SK6812, and more
- Dynamic lighting effects and color animations
PWM LED Strips (Non-Addressable)
Complete control for traditional LED strips:
- Single Color LED strips
- CCT (Tunable White) LED strips
- RGB LED strips
- RGBW LED strips (4-channel)
- RGBCCT LED strips (5-channel)
- Compatible with FC08, SMD5050, 3014, 3528, 5730, 5630, and COB LED types
SPI + PWM Combination Control
Advanced control capabilities for mixed installations:
- Control both addressable and non-addressable LEDs simultaneously
- Perfect for layered lighting designs
- Create sophisticated multi-zone effects
- Professional flexibility for complex projects
Why Choose WDM – Touch Panel?
✅ HIGH QUALITY ELECTRONICS COMPONENTS
Our products are made with top-of-the-line electronics components, ensuring reliable and long-lasting performance for years of dependable operation.
✅ EASY TO INSTALL AND USE
Our electronics products are designed to be user-friendly, with clear instructions and simple installation processes. Standard 86mm wall box compatibility ensures easy integration.
✅ VERSATILE APPLICATIONS
Our electronics products can be used in a variety of applications, including industrial, automotive, residential, commercial, and hospitality installations.
✅ MONEY-BACK GUARANTEE
Confidence comes from high quality and our continued pursuit for perfectness. We stand behind every product with complete satisfaction guarantee.
✅ EXCEPTIONAL CUSTOMER SUPPORT
We pride ourselves on providing exceptional customer support, with a knowledgeable team available to answer any questions or concerns about installation and operation.
Technical Specifications
| Specification | Details |
|---|---|
| Model Number | SP630E |
| Brand | WDM Lighting |
| Product Type | LED Touch Panel Controller |
| Panel Size | 86mm × 86mm × 12mm |
| Working Voltage | DC 5V-24V |
| Working Current | 3mA-13mA |
| PWM Single Channel Output | 6A maximum |
| PWM Total Maximum Output | 12A |
| Operating Temperature | -20℃ to 60℃ (-4℉ to 140℉) |
| SPI Pixel Capacity (RGB/CCT) | Up to 600 pixels |
| SPI Pixel Capacity (RGBW) | Up to 450 pixels |
| SPI Pixel Capacity (RGBCCT) | Up to 300 pixels |
| Wireless Technology | 2.4GHz RF |
| Control Range | 30 meters (98 feet) |
| Panel Battery | CR2032 (5V, included) |
| Quiescent Current | 26µA |
| Certification | CE, UL |
| Installation Area | Indoor |
| Compatible LED Types | 5050, 5630, 3528, COB, SPI Addressable |
| Material | High-quality ABS plastic |
| Water Resistance | Indoor use only (not water resistant) |
| Origin | Mainland China |
| Features | SPI + 5CH PWM, 2.4G wireless control |
Compatible LED Strip Chipsets
| Category | Supported Models |
|---|---|
| SPI Addressable Chips | WS2811, WS2812, WS2812B, WS2813, WS2814, WS2815, TM1804, TM1812, UCS1903, UCS1909, UCS1912, UCS2903, UCS2909, UCS2912, LB1934A, GW6205, GS8206, GS8208, SK6812 |
| PWM LED Strips (No IC) | FC08, SMD5050, 3014, 3528, 5730, 5630, COB |
| Configuration Options | 2-pin (V+ V-), 3-pin CCT (V+ CW WW), 4-pin RGB (V+ R G B), 5-pin RGBW (V+ R G B W), 6-pin RGBCCT (V+ R G B CW WW) |
Installation & Setup
The WDM – Touch Panel is designed for straightforward installation in standard wall boxes:
- Wall Box Preparation: Install standard 86mm wall box at desired location
- Controller Connection: Connect touch panel to WDM Lighting LED controller via 2.4GHz pairing
- Power Connection: Ensure LED controller has DC 5V-24V power supply matching your LED strip requirements
- LED Strip Connection: Wire your LED strips to the controller’s appropriate output terminals
- Panel Mounting: Secure touch panel to wall box using included mounting hardware
- Battery Installation: Install CR2032 battery (included) in touch panel
- Pairing: Follow pairing instructions to connect panel with LED controller
- Testing: Test all functions and zones before completing installation
Professional Installation Tip: The WDM – Touch Panel works seamlessly with WDM Lighting’s 12-in-1 Bluetooth Controller and other compatible 2.4GHz LED controllers for comprehensive lighting control systems.
Applications
Perfect for a wide range of professional lighting installations:
- Residential: Living rooms, bedrooms, hallways, home theaters, accent lighting control
- Commercial: Offices, retail displays, restaurants, bars, reception areas
- Hospitality: Hotels, resorts, spas, conference rooms, ballrooms
- Healthcare: Patient rooms, waiting areas, corridors (adjustable color temperature)
- Entertainment: Theaters, performance venues, event spaces, gaming rooms
- Architectural: Building lobbies, atriums, galleries, museums
System Integration
The WDM – Touch Panel integrates seamlessly with WDM Lighting’s complete LED control ecosystem:
- WDM Lighting 12-in-1 Bluetooth Controller: Primary controller for comprehensive LED strip support
- Multiple Touch Panels: Install panels in different rooms for convenient multi-location control
- Zone Control: Manage up to 4 independent lighting zones from single panel
- Remote Control Compatibility: Works alongside 2.4G remote controls for flexible control options
- BanlanX App: Coordinate with smartphone app control for complete lighting management
What’s in the Box
- 1× WDM – Touch Panel Controller (Model SP630E)
- 1× CR2032 Battery (pre-installed or included)
- Mounting Hardware
- Quick Start Installation Guide
Note: LED controller, power supply, and LED strips sold separately. Compatible with WDM Lighting 12-in-1 Bluetooth Controller and other 2.4GHz RF LED controllers.
Transform Your Space with Professional Touch Control
The WDM – Touch Panel offers elegant, wall-mounted LED control with professional-grade performance and universal compatibility.
Professional touch panel control for residential, commercial, and hospitality installations.
