WDM-Bluetooth Remote Control
Professional 2.4GHz RF Remote with 98-Foot Range, 4-Zone Control, and BanlanX App Integration
View Product Details
WDM-Bluetooth Remote Control
Professional RF remote control with 2.4GHz wireless technology, 98-foot range, and intuitive 4-zone management for complete LED lighting control
Key Features at a Glance:
- 98-Foot Range: 2.4GHz RF wireless technology
- 4-Zone Control: Independent zone management
- Universal Compatibility: Works with WS2812B, RGB, RGBW strips
- BanlanX App Integration: Smartphone control with music sync
- Multi-Controller Support: One-to-many and multi-to-one control
- 1200+ ICs Supported: Professional addressable LED capacity
📞 Call: 972-650-1855
Why Professional RF Control Matters
🚫 The Problem
Traditional Bluetooth controllers have limited range and require line-of-sight operation. Managing multiple LED zones becomes complicated without proper remote infrastructure, forcing installers to position controllers awkwardly or sacrifice control flexibility in larger installations.
✅ The Solution
The WDM-Bluetooth Remote Control uses 2.4GHz RF technology for reliable 98-foot range that penetrates walls and obstacles. Control up to 4 independent zones, manage multiple controllers from one remote, or use multiple remotes for the same system—perfect for residential, commercial, and entertainment installations.
What Makes This Remote Different?
Most LED remotes offer basic on/off control with limited range. This professional RF remote delivers comprehensive zone management, extensive compatibility, and seamless app integration for complete lighting control.
2.4GHz RF Technology
Superior 98-foot range that penetrates walls and obstacles. No line-of-sight required. Reliable control throughout your entire installation without Bluetooth limitations or Wi-Fi dependencies.
4-Zone Management
Control up to 4 independent lighting zones from a single remote. Perfect for multi-room installations, layered lighting designs, or commercial spaces requiring separate zone control with professional precision.
BanlanX App Integration
Seamless integration with the free BanlanX app for iOS and Android. Combine physical remote control with smartphone features including music sync, custom scenes, dynamic effects, and 5 programmable timers.
Universal Compatibility
Works with both SPI addressable strips (WS2811, WS2812B, WS2813, WS2814, WS2815, SK6812) and PWM strips (RGB, RGBW). Supports up to 1200 addressable ICs for professional-scale installations.
Music Synchronization
Three audio capture modes: mobile phone microphone, player streaming, and built-in high-sensitivity microphone. Create dynamic audio-reactive lighting that responds to music in real-time.
Flexible Control Options
One remote to many controllers, many remotes to one controller, or any combination. Compatible with other WDM remotes for installations requiring multiple control points or backup remote capabilities.
Complete Control Capabilities
The WDM-Bluetooth Remote Control offers comprehensive control options that scale from simple residential installations to complex commercial lighting systems.
Multi-Zone Control
Manage up to 4 independent lighting zones from a single remote:
- Zone 1-4 Individual Control: Each zone operates independently with dedicated buttons
- All-Zone Control: Synchronize all zones simultaneously for unified effects
- 30-Meter Range Per Zone: Each zone maintains full 98-foot control distance
- Flexible Zone Assignment: Assign LED strips to specific zones during setup
One-to-Many Control
Control multiple LED controllers from a single remote:
- Perfect for installations spanning multiple rooms or areas
- Synchronize lighting effects across entire buildings
- Centralized control for commercial installations
- Maintain consistent lighting throughout your space
Multi-to-One Control
Use multiple remotes to control the same LED system:
- Provide control access from different locations
- Family members each have their own remote
- Install remotes in multiple convenient locations
- Backup remote capability for critical installations
Complete LED Strip Compatibility
Works seamlessly with both addressable SPI LED strips and traditional PWM strips, supporting all major IC chip models and LED configurations.
| LED Strip Type | Supported Models | Maximum ICs |
|---|---|---|
| SPI RGB Addressable | WS2811, WS2812, WS2812B, WS2813, WS2814, WS2815 | 1200 ICs |
| SPI RGBW Addressable | SK6812, SK6812RGBW, compatible RGBW chips | 900 ICs |
| PWM RGB Strips | FCOB, SMD5050 4-pin RGB (V+ R G B) | Limited by amperage |
| PWM RGBW Strips | FCOB, SMD5050 5-pin RGBW (V+ R G B W) | Limited by amperage |
| LED Matrix | WS2812B matrices: 8x8, 8x16, 8x32, 11x44, 16x16, 32x32 | 1200 pixels max |
Technical Specifications
Wireless Performance
- Technology: 2.4GHz RF
- Range: Up to 30 meters (98 feet)
- Zones: 4 independent control zones
- Pairing: Multi-device support
LED Compatibility
- SPI RGB: 1200 IC maximum
- SPI RGBW: 900 IC maximum
- PWM: 4CH RGB, 5CH RGBW
- Voltage: DC 5V-24V systems
App Integration
- App Name: BanlanX (Free)
- Platforms: iOS and Android
- Music Modes: 3 capture methods
- Timers: 5 programmable timers
Physical Specs
- Power: Battery operated (included)
- Material: Durable plastic housing
- Operating Temp: -4℉ to 140℉
- Waterproof: IP30 (indoor use)
Real-World Applications
From home automation to commercial installations and entertainment venues, the WDM-Bluetooth Remote Control adapts to any lighting project.
Residential
- Smart home lighting automation
- Multi-room control systems
- Entertainment room ambiance
- Under-cabinet and accent lighting
- Home theater control
- Bedroom and living area zones
Commercial
- Restaurant mood lighting control
- Retail display illumination
- Hotel and hospitality zones
- Office lighting management
- Showroom multi-zone control
- Reception and lobby areas
Entertainment
- DJ booth and stage control
- Bar and nightclub lighting
- Event venue management
- Theater production lighting
- Gaming room setups
- Concert and performance spaces
Architectural
- Building facade lighting control
- Landscape feature illumination
- Multi-floor zone management
- Corridor and hallway systems
- Atrium lighting control
- Large-scale installations
Frequently Asked Questions
Ready to Upgrade Your LED Control?
Experience professional-grade wireless LED control with 98-foot range, 4-zone management, and seamless app integration. Perfect for residential, commercial, and entertainment installations.
Order Now - $30📞 Call: 972-650-1855
