10D Downlight

10D Downlight

Call for Price

This product is currently out of stock and unavailable.

SKU: UFO-10D Category:

Product Description

The UFO 10D Downlight A adjustable downlight fitting with trumpet, secured through the mounting surface with spring clips. Available in a range of finishes, this fitting can be rotated and tilted to point directly at any objects to be illuminated. The light beam from this fitting is also focusable. Also suitable for mounting in the base of a display case and illuminating upwards.

Technical Specifications Lens:

  • Clear focusing lens
  • Material: Aluminum; stainless steel; polycarbonate
  • Colors available: White or chrome
  • Focus range: 25° – 45°
  • Flange size: 50mm (1″)
  • Tilt: 28°
  • Rotate: 360°
  • Weight: 140.7g (0.31lb)
  • Mounting method: Recessed, held by springs
  • Mounting hole size: 40mm (1.58″)
  • Ferrule size: M10 or 8mm (0.31″)smooth
  • Min. fiber size: 2mm (0.08″) Max. fiber size: 8mm (0.31″)

Download specification sheet.
Download installation guide.

Additional Information

Weight 0.3125 lbs
